Belt Conveyor
Your Professional Belt Conveyor Supplier
Our goal is to become your reliable partner in the AGV And RGV in China. Huishan High-Tech Industrial Development Zone, Wuxi, Jiangsu Province, LEEV is an integrated enterprise specializing in R&D, manufacturing, sales, and service. We are committed to applying advanced manufacturing technologies and strict quality control standards to every product. Our products are quality-assured, making us a dependable choice for long-term cooperation.
Why Choose Us
Production Equipment
Our company boasts advanced production equipment, including laser cutting machines, CNC punching machines, CNC shearing machines, CNC bending machines, welding machines, grinding machines, 34 bridge cranes, 5 forklifts, and 5 air compressors.
Our Certifications
Our company holds ISO 14001 Environmental Management System Certification, ISO 45001 Occupational Health and Safety Management System Certification, and Information Technology and Industrialization Integration Management System Certification.
One-Stop Solution
In addition to equipment supply, we also provide technical support, solution upgrades, market insights, and invite customers to experience our production, culture, and operations firsthand.
Advantages of Belt Conveyor
Flexible customization
Non-standard design based on factory layout, takt time, and material properties.
High-quality PVC belt
Wear-resistant, anti-slip, smooth operation, service life over 15 years (excluding electrical components).
Anti-tracking design
Large conical rollers prevent belt deviation for stable long-term operation.
Low maintenance
Simple and reliable structure suitable for continuous operation (light duty belt conveyor).
Specification of Belt Conveyor
|
No. |
Item |
Specification |
|
1 |
Dimensions |
L3000 × W1000 × H800 mm, customizable |
|
2 |
Load Capacity |
25 kg/m² |
|
3 |
Speed |
0–25 / 0–65 m/min, VFD adjustable (variable speed conveyor) |
|
4 |
Motor Power |
0.75 / 1.5 kW |
|
5 |
Drive & Idler Rollers |
φ132 knurled steel rollers |
|
6 |
Support Wheels |
Steel wheels with anti-derail device |
|
7 |
Upper & Lower Rollers |
Φ50 × 1.5 mm hot-dip galvanized tube |
|
8 |
Belt |
3 mm thick PVC, green or gray |
The belt conveyor is a light-duty assembly line conveyor designed for single-piece transportation or manual workstation support. It operates smoothly and continuously, controlled via buttons or photoelectric sensors, reducing manual labor and improving workstation efficiency.
Types of Belt Conveyor
Roller bed belt conveyor: A roller bed belt conveyor features a surface beneath the belt composed of closely spaced rollers. This conveyor design is popular in automated material handling because the rollers minimize belt sag and friction, supporting the belt as it moves heavy or bulky items.
Flat belt conveyor: Flat belt conveyors are among the most widely used in industrial conveyor systems for moving a wide range of products within distribution centers, assembly plants, and warehouses.
Modular belt conveyor: Modular belt conveyors utilize a chain of interlocking rigid plastic or metal modules instead of a traditional continuous flexible belt.
Cleated belt conveyor: Cleated belt conveyors are equipped with built-in barriers (cleats) at predefined intervals to create individual compartments on the belt surface. These cleats prevent items from rolling or sliding back, especially useful when elevating materials on incline or decline conveyor systems.
Application of Belt Conveyor
Mining & quarrying
Moving heavy, bulk materials like coal, aggregate, and ore over long distances, often replacing trucks to reduce environmental impact.
Food & pharmaceutical industry
Sanitary transport of food, produce, or medicine through processing, washing, cooking, and packaging stages using food-grade, easy-to-clean belts.
Manufacturing & assembly lines
Transporting components between workstations and assembly points, particularly for lightweight items or consumer goods.
Warehouse & logistics
Sorting and conveying packages, boxes, and goods in distribution centers to optimize shipping efficiency.
Airport baggage handling
Moving passenger luggage from check-in to sorting areas and on to aircraft.
Recycling & waste management
Transporting waste and sorting recyclable materials, including paper, plastics, and metals.
Other Service of Belt Conveyor
|
Package |
Wooden pallets |
|
Shipping |
Sea/Express |
|
Payment |
We accept T/T and L/C. For samples or small trial orders |
